The LP6460A contains an independent 600KHz constant frequency, current mode, PWM step-down converters. The converter integrates a main switch and a synchronous rectifier for high efficiency without an external Schottky diode. The LP6460A is ideal for powering portable equipment that runs from a 2cell Lithium-Ion (Li+) battery. The converter can supply 2000mA of load current from a 3.5V to 16V input voltage. The output voltage can be regulated as low as 0.6V. The LP6460A is available in a SOT23-6 package and is rated over the -40℃ to 85℃ temperature range.

■ 产品概述 XT3410 是一款由基准电压源、振荡电路、比较器、 PWM/PFM 控制电路等构成的 CMOS 降压型 DC/DC 调整 器。利用 PWM/PFM 自动切换控制电路达到可调占空比，具 有全输入电压范围内的低纹波、高效率和大输出电流等特点。 XT3410 内置功率 MOSFET，集成了过压、过流、过热、 短路等诸多保护电路，在超过控制值时会自动断开，以保护 芯片。本产品结合了微型封装和低消耗电流等特点，最适合 在移动设备的电源内部使用。
