24C02
FEATURES Low voltage and low power operations: AISK24C02: VCC = 1.8V to 5.5V, Industrial temperature range (-40℃ to 85℃). AISK24C02-Kxx: With 3 bits device address, the devices are suitable for all application. (For use of 5 pins package, the device address A2,A1,and A0 bits must be set to zero) Maximum Standby current < 1µA (typically 0.02µA and 0.06µA @ 1.8V and 5.5V respectively). 16 bytes page write mode. Partial page write operation allowed. Internally organized: 256 × 8 (2K). Standard 2-wire bi-directional serial interface. Schmitt trigger, filtered inputs for noise protection. Self-timed programming cycle (5ms maximum). 1 MHz (2.5-5V), 400 kHz (1.8V) Compatibility. Automatic erase before write operation. Write protect pin for hardware data protection. High reliability: typically 1,000,000 cycles endurance. 100 years data retention. Standard 8-pin DIP/SOP/MSOP/TSSOP/DFN and 5-pin SOT-23/TSOT-23 Pb-free packages.
DESCRIPTION The AISK24C02 is 2048 bits of serial Electrical Erasable and Programmable Read Only Memory, commonly known as EEPROM. They are organized as 256 words of 8 bits (1 byte) each. The devices are fabricated with proprietary advanced CMOS process for low power and low voltage applications. These devices are available in standard 8-lead DIP, 8-lead SOP, 8-lead MSOP, 8-lead TSSOP, 8-lead DFN and 5-lead SOT-23/TSOT-23 packages. A standard 2-wire serial interface is used to address all read and write functions. Our extended VCC range (1.8V to 5.5V) devices enables wide spectrum of applications.
